A2FPM Single Compression Cable Gland
We are India's leading manufacturer, supplier, and exporter of Single Compression Cable Glands used for non-armoured cables in Rigid Conduits & Metal Pipes.
| Type | A2FPM Single Compression Cable Gland |
|---|---|
| Cable Types | Unarmoured |
| Application | A2FPM cable glands for non-armoured cables in Rigid Conduits & Metal Pipes.
Male thread on the outlet gives the possibility to connect Pipes and Hoses. It is easy to use and install as it has free rotating Female Bush for Connection. |
| Gland Material | Brass (CuZn39Pb3), Stainless Steel (304 or 316L) |
| Option Thread | Metric, NPT, BSP |
| IP Rating | IP66 |
| Seal type | Displacement type |
| Operating Temperature | Standard Seals (Nitrile): -20°C to 80°C. on request (Silicone) :-60°C to +180°C |
| Finish | Natural Brass or Nickel Plated or Electroless Nickel Plated |
| Accessories | PVC / LSF Shroud, Lock Nut, Earth Tag, Serrated Washer, Adaptor / Reducer |
| EAC Certificate No. | RU C-IN.AA71.B.00212/20 |
| Protection Type | 1Ex e IIC Gb X / 1Ex d IIC Gb X /
2Ex nR IIC Gc X / Ex ta IIIC Da X |
AVAILABLE ENTRY THREAD “C” (ALTERNATE METRIC THREAD LENGTHS AVAILABLE)
Size Chart / Specification
| CODE | CABLE GLAND SIZE | ENTRY THREAD "C" | THREAD LENGTH "E" | CABLE DIAMETER "A" | M | N | MALE CONNECTION THREAD "D" | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| METRIC | NPT | METRIC | NPT | MIN | MAX | MAX | MAX | METRIC | NPT | BSP | ||
| MM-EX-A2FPM-20S16 | 20S16 | M20 | 1/2" | 17 | 20 | 3.2 | 8.5 | 24 | 26.5 | M16 | 3/8" | 3/8" |
| MM-EX-A2FPM-20S | 20S | M20 | 1/2" | 17 | 20 | 6.2 | 11.6 | 24 | 26.5 | M20 | 1/2" | 1/2" |
| MM-EX-A2FPM-20 | 20 | M20 | 1/2" | 17 | 20 | 8.0 | 13.9 | 27 | 30 | M20 | 1/2" | 1/2" |
| MM-EX-A2FPM-25 | 25 | M25 | 3/4" | 17 | 21 | 11.2 | 19.6 | 36 | 40 | M25 | 3/4" | 3/4" |
| MM-EX-A2FPM-32 | 32 | M32 | 1" | 17 | 26 | 17.1 | 26.0 | 42 | 46 | M32 | 1" | 1" |
| MM-EX-A2FPM-40 | 40 | M40 | 11/4" | 17 | 26 | 23.6 | 31.6 | 50 | 55 | M40 | 11/4" | 11/4" |
| MM-EX-A2FPM-50S | 50S | M50 | 11/2" | 17 | 26 | 31.1 | 37.5 | 55 | 60 | M50 | 11/2" | 11/2" |
| MM-EX-A2FPM-50L | 50 | M50 | 2" | 17 | 27 | 35.7 | 43.1 | 65 | 70 | M50 | 2" | 2" |
| MM-EX-A2FPM-63S | 63S | M63 | 2" | 17 | 27 | 41.6 | 48.7 | 70 | 77 | M63 | 2" | 2" |
| MM-EX-A2FPM-63L | 63 | M63 | 21/2" | 17 | 40 | 47.3 | 55.2 | 80 | 89 | M63 | 21/2" | 21/2" |
- All the dimensions given are in Millimeters (mm)
- Can be also provided in Kit Packing as per requirement
Disclaimer: Product sizes mentioned in the catalogue are for reference purpose only. The actual dimensional details would be available only after request based on the actual requirement.
